Ergotron Neo-Flex - Instructions du kit M8 M5

11 of 21
888-24-073-W-03 rev. T • 01/19
4x
4x
4x
4x
M5 x 20mm
M5 x 20mm
Instructions du kit M8M5
Trou de montage de téléviseur/
d’écran de taille M8
Trou de montage de téléviseur/
d’écran de taille M8
Anneau de support (non inclus *
Samsung uniquement)
NOTE: Follow this step only if your TV/monitor has M8 holes which need to be
reduced to M5.
NOTE: Follow this step only for Samsung models using the holder ring.
Install M8M5 reducer bushing to TV/Monitor and use M5 x 20 mm monitor
screws to secure.
Install M8M5 reducer bushing to TV/Monitor then use M5 x 20 mm monitor screws
and Samsung holder ring to secure.
