Erickson 07496 - Parts Diagram and Identification

7
Item no: 07496
PARTS DIAGRAM
1
2
3
4
12
9
10
11
5
6
8
7
Part# Description Qty
1 Supporting frame 2
2 Connecting piece 2
3 M10*20 carriage bolt 12
4 M10 lock nut 14
5 Support brace 2
6 50 square tube 1
Part# Description Qty
7 Tie plate 1
8 M10*83 carriage bolt 2
9 Left and right side fencing 2
10 Front/Back Left fencing 2
11 Front/Back Right fencing 2
12 Ring bolt 4
