erlab Captair 834 Smart - Page 5

Assembly Instructions - Notice de Montage - Instrucciones de Montaje - Montage Beschreibung - Istruzioni per il Montaggio
5
Parts list - Liste des pièces - Lista de piezas - Teileliste - Elenco delle parti
Mechanical parts / Pièces mécaniques et câbles / piezas mecánicas/
mechanische Teile / parti meccaniche /
Ref. Qty.
Designation
Spare part
A
x1 Base / Socle / Zócalo / Sockel / Zoccolo
PIDREB03P3008
B
x1 Back panel / Panneau arrière / Panel trasero / Rückwand / Pannello posteriore
PIDREB03P3007
C
x2 Side panel / Pied porteur / Apoyo / Standsockel / Piede portante
Droite
PIDREBP3005
Gauche
PIDREB03P3004
D
x1 Partition / Cloison / Tabique / Partition / Partizione
REB03P3006
E
x1
Control panel / Panneau de contrôle / Panel de control / Kontrolltafel /
Pannello di controllo
321: K77 391: K78
481: K79 834: KPS
1634: KQS
F
x2 Side cover / Carter / Cárter / Gehäuse / Coperchio
DI8523
G1
x2 Frame / Cadre / Quadro / Rahmen / Cuadro
13351000001
G2
X2
Transparent door / portes transparentes / porta transparente /
transparente Türen / puertas transparentes
G3
X2 Handle / poignée / manica / Griff / maneja
G4
X8
Storage bins / Bac de rangement / Contenitori di stoccaggio /
Sichtlagerkästen / Contenidores de almacenamiento
H
X1 RJ45 cable / Câble RJ45 / cable RJ45 / RJ45-Kabel / Cavo RJ45
WEL8603
I
X1
Power cable / Cable d’alimentation / Cable de alimentación / Stromkabel / Cavo di
alimentazione
EU = PIDEL076
USA = PIDEL080
GB = PIDEL090
CH = PIDEL106
Screws / Visserie / Tornillos/ Schrauben / Viti /
Ref. Qty.
Designation
Spare part
S1
x26
Hex Head Screw / Vis tête hexagonale / Tornillos de cabeza hexagonal /
Sechskantschraube / Viti con testa esagonale
PIDBOX037
Washer / Rondelles / Rondelle / Scheibe / arrandelas
S2
x40
Round Pan Head, «Poëlier»/ Vis poelier / Tornillos Poelier/ Poelier Schraube/ Viti
Poëlier
PIDB0030
S3
x4 Nylon screws / Vis nylon / Tornillo nailon / Nylonschraube / Viti nylon
PIDB08547
S4
x4 CHC screw / vis CHC / Viti CHC / CHC Schraube / Tornillos CHC
PIDBO8562
Filtration column / colonne de filtration / filtrazione modulabile /
Kolonnen-Filtrationssystem / filtración modular/
Ref. Qty.
Designation
Spare part
N1
See,
Voir
Consulte
Siehe
Vedi
p.10
Carbon lter / Filtre carbone / Filtro carbone / Kohleltern / Filtro carbone
H11074101 (AS)
H11074201 (BE+)
H11074401 (F)
H11074301 (K)
N2
HEPA H14 / ULPA U17 Filter / Filtre HEPA H14/ ULPA U17 / Filtro HEPA H14/ ULPA
U17 / HEAP H14 / ULAP U17 Filtri
H11074031 (HEPA H14)
H11074051 (ULPA U17)
N3
HEPA lter seal frame / Cadre joint pour ltre HEPA / Cuadro junta para ltro HEPA
/ Abdichtungsrahmen für Hepa-Filter / Quadro giuntivo per ltro HEPA
PIDDI8532
N4
x1
Fan module / Boîtier de ventilation / Módulo ventilador / Ventilatorengehäuse / Cas-
sone di ventilazione
Z3FM004
N5
Fan module + grid / Boîtier de ventilation + grille / Módulo ventilador + rejilla/ Venti-
latorengehäuse + Gitter /
Cassone di ventilazione + griglia - 1C - 1P - 1P1C
Z3FM004 + PIDMS8522
