1. Ensure that the helmet is always fitted with an outer and inner protection lens
2. These protection lenses must be replaced if broken, damaged or covered with welding
spatter to the extent that vision is impaired.
3. Outer and Inner protection lenses are consumables and must be replaced regularly with
genuine certified spare parts.
4. The outer protection lens is loaded though the back, see above illustration.
5. The inner lens is loaded through back into the locaters on the auto darkening filter.
Protection marked in accordance with this standard is only provided when all lens and
retention components are installed according to the list of manufactures instructions
6. Change dark shade from 9 to 13 and grind mode as desired by using the variable
adjustment knob. Refer to Table 1 below if necessary.
7. Adjust the Sensitivity and Delay Time as desired by using the variable adjustment knob
8. When the helmet is not used for 15 minutes the power will automatically shut-off. There
is no OFF switch.
