5.2 Installing and charging the battery
1
Rotate the battery house cover knob
to “Unlock” position; Pull battery
house cover out.
2
Insert battery into battery house.
3
Close battery house cover and turn
the knob to “Lock” position
4
Take battery out from battery housing
and charge battery
The battery is partially charged when delivered. It is recommended to charge the
It is recommended to charge the batteries at 100% before each use.
The charger must not be used for anything else than it was designed for. Do not
charge the battery in a potentially explosive area. The charger must only be used indoors.
The charger regulates the charge automatically, once the battery is fully charged, it will
The charge time is 3 to 4 hours.
The battery will discharge itself after long storage periods. Always charge the bat-
tery if the device was stored for more than 15 days. When the battery is new or has been
stored for more than 3 months, charge it and discharge it at least twice in a row to resume
the nominal/rated charge capacity.
Battery charge:
1. Take battery out from battery housing
2. Connect the battery to the charger using the input located at the top of the battery.
3. Connect the charger to the main power source.
4. The state of charge is displayed via a red LED on the main power source charger.
5.
OFF and a green LED switches ON.
6. Disconnect the charger from the outlet (do not keep the charger plugged to the main
power source if it’s not in use).
