SECTION 2 DESCRIPTION
BOOM WITH CAGE & CONTROL BOX BRACKET
BOOM SHOWING WIREFEEDER & CONTROL BOX PLACEMENT
Figure 2-3 SPLIT HEAVY DUTY VERSION (SHD)
Wire Drive / Drive Box
Feeder Mount Bracket
Boom Mast
Control Box
