Esatto ECD7 - Page 8

User Manual
08
8 9
Catalogue
Part description
Part Description
Power Cord
Lint Filter
Container
Door
Control panel
Air inlet
Handle
Maintenance cover
Drum
Accessories
The following parts are optional for specific models.
If your dryer has following parts, please them instruction
below .
install following the
Hose holder(optional)
Condensing drain
hose(optional)
Step 1: removing the drain hose from the
hose connector using plier.
Step 2: insert the external drainage hose.
Installation step:
Part description
Quick start
1.Check if the container and filters
have been cleaned up
3. Close the machine door
2. Open the door and
load the laundry
4. Plug the power cord and
press the【On/Off】button
8.Press the 【 】buttonOn/Off
7. Remove the laundry when
6. Press the 【Start/Pause】button
9. Clean the filters and
empty container
10.Unplug the power cord
5. Select the desired
programme
finished
Max. 120cm
200cm
Step 3: put the hose holder on the washing basin or any other sink.
