This document is the user manual for the Esatto 7kg Vented Dryer, model EVD7. It provides comprehensive information on the appliance's function, technical specifications, usage, and maintenance.

Function Description:

The Esatto 7kg Vented Dryer is designed for drying clothes, towels, and linen in a domestic environment. It operates by tumbling clothes in a heated drum and venting the moist air outside. The dryer offers various drying programs and dryness levels to suit different fabric types and desired results. It includes optional features like an Anti-Crease function and a Child Lock for enhanced usability and safety. The final cycle of all drying programs is a cool-down cycle to reduce the temperature of clothes and prevent damage.

Important Technical Specifications:

Product: 7kg Vented Dryer
Model Code/s: EVD7
Dimensions (w, d, h): 595 x 555 x 840mm
Weight of product: 35kg
Rated input power: 2000W
Rated volume of dryer: 7.0kg (Dry clothes)
Rated voltage: 220-240V~
Rated frequency: 50Hz
Maximum capacity for loads: 7kg (based on dry clothing)

Usage Features:

The dryer features a user-friendly control panel with a power button, start/pause button, drying program selector, dryness level selector, and an anti-crease mode button.

Drying Programs:

1 Hour: A quick drying option.
Synthetic: Suitable for synthetic fabrics.
Cotton: Designed for cotton items.
Mix: For mixed loads.

Dryness Levels:

Light: For items that require minimal drying or are slightly damp.
Standard: A general-purpose dryness level.
Extra Dry: For thoroughly dry clothes.

Optional Functions:

Anti-Crease Function: Adds a short period of tumbling at the end of the program to reduce wrinkles. Activated by pressing the Anti-Crease button, indicated by an LED light.
Child Lock: Locks the controls to prevent accidental operation. Activated by simultaneously pressing the "Program" and "Dryness" buttons for 3 seconds, indicated by an LED light next to the lock symbol.

General Operation Guidelines:

Loading: For faster drying, load the dryer to ½ to ⅔ capacity of the drum to allow even circulation of clothes and air.
Sorting: Sort clothes by fabric type and drying time (heavier items separate from light items).
Care Labels: Always check clothing care labels for suitability for tumble drying and recommended temperatures.
Over-drying: Avoid over-drying to prevent creases and static charges.
Static Charge: Use fabric softener during washing or a fabric conditioner specifically for tumble dryers to reduce static.
Unwashed Items: Never dry unwashed items.
Unsuitable Items: Do not tumble dry delicate items (net curtains, woollen, silk, items with metal trim), bulky materials (blankets, eiderdown), rubber foam, or rubber-backed articles due to fire risk or damage.
Pockets: Ensure all objects are removed from pockets.
Fasteners: Close all press studs, hooks, eyes, and zips to prevent tangling.
Lint: Some fabrics (towels, nappies, chenille) give off lint, while others (corduroy, synthetics, permanent press) collect it. Separate these to minimize lint transfer.

Installation Instructions:

The dryer can be placed freestanding or wall-mounted.

Freestanding: Requires a minimum of 80mm clearance from the top to the ceiling and 10cm from walls/cabinetry.
Wall Hanging: Detailed instructions are provided for wall mounting, including using a screw position template, expansion bolts, and hanging brackets. It's crucial to mount on a solid wall and ensure the power cord is accessible. Two or more people are required for lifting and installing the dryer for safety.
Ventilation: The dryer requires an unrestricted air supply and exhaust ventilation. Ensure vents are not blocked.
Power Source: Must be plugged directly into a properly earthed AC power supply. Avoid extension cords, power boards, or double adaptors for safety.

Maintenance Features:

Lint Filter Cleaning: The lint filter, located inside the door, must be cleaned after each and every load. A clean filter improves efficiency, reduces drying times, saves energy, and prevents overheating and potential fire hazards. A torn or damaged lint filter must be replaced immediately.
Inner Drum Cleaning: Wipe the inner drum and cabinet with a soft, slightly damp cloth. Avoid excessive water, scouring pads, abrasives, alcohol wipes, or harsh cleaning chemicals.
Periodic Inspection: It is recommended to have a qualified appliance technician inspect and clean the dryer periodically to avoid potential fire hazards.

Troubleshooting:

The manual includes a troubleshooting section for common issues:

Dryer not starting: Check power connection, fuses, and ensure the door is fully closed.
Clothes still wet: Select a longer drying time, check for blocked lint filter, and ensure adequate room temperature (below 12°C may require longer drying).
Error Codes:
- E1 (Light dryness level LED flashes): Dryer temperature is too hot. Possible causes include overloading, blocked ventilation, or a blocked lint filter. Action: Switch off, unplug, open the door, correct load, clean lint filter, ensure ventilation.
- E2 (Light & Standard dryness level LED flashes): Temperature sensor error. Action: Switch off, unplug, leave for 15 minutes, then reconnect.
- E3 (Extra dryness level LED flashes): Temperature sensor error. Action: Switch off, unplug, leave for 15 minutes, then reconnect.

Warranty Information:

The manual provides detailed warranty terms and conditions for Australia and New Zealand, covering manufacturing defects for 24 months from the date of purchase. It outlines conditions for making a claim, exclusions (e.g., damage from misuse, improper installation, normal wear and tear), and contact information for customer support and spare parts.
