Manual of Sensorless Brushless Motor Speed Controller Ver HW-01-081027.1
- 4 -
Normal startup procedure:
Throttle range setting: (Throttle range should be reset whenever a new transmitter is being used)
Program the ESC with your transmitter (4 Steps):
1. Enter program mode
2. Select programmable items
3. Set item’s value (Programmable value)
4. Exit program mode
1. Enter program mode
1) Switch on transmitter, move throttle stick to
top , connect the battery pack to ESC
2) Wait for 2 seconds, the motor should emit
special tone like “beep-beep-”
3) Wait for another 5 seconds, special tone like
“
” should be emitted, which means
program mode is entered
4. Exit program mode
There are 2 ways to exit
program mode:
1. In step 3, after special
tone “
”, please
move throttle stick to
the bottom position
within 2 seconds.
2. In step 2, after tone
“beep-----beep-----”(ie.
The item #8), move
throttle stick to bottom
within 3 seconds.
3. Set item value (Programmable value):
You will hear several tones in loop. Set the value matching to a tone by moving throttle stick
to top when you hear the tone, then a special tone “
” emits, means the value is set
and saved. (Keeping the throttle stick at top, you will go back to step 2 and you can select
other items; Moving the stick to bottom within 2 seconds will exit program mode directly)
Tones
Items
“beep-”
1 short tone
“beep-beep-”
2 short tones
“beep-beep-beep”
3 short tones
Brake
Off On
Battery type
Li-ion / Li-poly NiMH / NiCd
Cutoff mode
Soft-Cut Cut-Off
Cutoff threshold
Low Medium High
Start mode
Normal Soft Super soft
Timing
Low Medium High
2. Select programmable items:
After entering program mode, you will hear 8 tones in a loop with
the following sequence. If you move the throttle stick to bottom
within 3 seconds after one kind of tones, this item will be selected.
1. “beep” brake (1 short tone)
2. “beep-beep-” battery type (2 short tone)
3. “beep-beep-beep-” cutoff mode (3 short tone)
4. “beep-beep-beep-beep-” cutoff threshold (4 short tone)
5. “beep-----” startup mode (1 long tone)
6. “beep-----beep-” timing (1 long 1 short)
7. “beep-----beep-beep-” set all to default (1 long 2 short)
8. “beep-----beep-----” exit (2 long tone)
Note: 1 long “beep-----” = 5 short “beep-”
Switch on
transmitter,
move throttle
stick to top
Connect battery
pack to ESC,
and wait for
about 2 seconds
“Beep-Beep-” tone
should be emitted,
means throttle range
highest point has been
correctly confirmed
Move throttle stick to the
bottom, several “beep-” tones
should be emitted, presenting
the number of battery cells
A long “Beep-” tone should
be emitted, means throttle
range lowest point has
been correctly confirmed
Move throttle
stick to
bottom and
then switch
on transmitte
