2017 Escalade Sports
For Customer Service Call 1-888-996-2729
15
All Rights Reserved.
Congratulations! You have now assembled your soccer table. Please note the Care and Use
instructions below to insure many years of trouble free use of your soccer table.
CARE AND USE OF YOUR LED AZURE SOCCER TABLE
1. Apply a few drops of lubricant (not provided) to the rods and the bushings.
Rotate rods to make sure you spread lubricant evenly.
2. Use spray furniture polish to clean all exterior surfaces of your soccer table.
3. Use a carpenters level to properly level table using the leg levelers.
4. This product is intended for INDOOR use only.
5. DO NOT sit, climb or lean on the table.
6. DO NOT drag the table when moving it. This will damage the legs.
7. DO NOT set drinks on the table.
8. Table LED’s and scoring will automatically turn off after a few minutes of non-play.
Description
Qty.
H1
H2
H3
H4
H5
H6
H7
T2
P1R
P2R
P3R
P4R
P5
P6R
P7
P8
P9
P10
P11
P12
P13
Key # Part #
PRODUCT PARTS LIST FOR MODEL # G01344
G01344HLH1
G01344HLH2
G01344HLH3
G01344HLH4
G01344HLH5
G01344HLH6
G01344HLH7
G01344HLT2
G01344HLP1R
G01344HLP2R
G01344HLP3R
G01344HLP4R
G01344HLP5
G01344HLP6R
G01344HLP7
G01344HLA4
G01344HLP9
G01344HLP10
G01344HLP11
G01344HLP12
G01344HLP13
3.5 mm x 35 mm Phillips Round Head Screw
3.5 mm x 18 mm Phillips Flat Head Screw
3.5 mm x 14 mm Phillips Round Head Screw
6 mm x 50 mm Allen Head Bolt
8.5 mm x 22 mm Flat Washer
6.5 mm x 16 mm Flat Washer
8 mm x 38 mm Allen Head Bolt
M5 Allen Wrench
Side Apron- A with C6 Connection Module attached
Side Apron- B
End Apron- A
End Apron- B with Electronic Scorer & C1 Junction Box Attached
Playfield
Leg with LED wire connection
Playfield Support Brace with brackets attached
A/C Adapter
Leg Leveler
2-Player Rod
3-Player Rod
5-Player Rod
Plastic Rod Washer
8
4
8
8
16
8
8
H8
H9
H10
H11
G01344HLH8
G01344HLH9
G01344HLH10
G01344HLH11
8 mm x 50 mm Allen Head Bolt
3.5 mm x 12 mm Phillips Flat Head Screw
M4 x 27 mm Phillips Round Head Bolt
M4 Nylock Locknut
8
4
26
26
1
T1
G01344HLT1
M4 Allen Wrench
1
1
1
1
1
1
G01344HLP19
Ivory Player
13
4
2
1
4
2
4
2
16
P14
P15
P16
P17
P18
P19
G01344HLP14
G01344HLP15
G01344HLP16
G01344HLP17
G01344HLP8
G01344HLP18
Rubber Rod Bumper
Manual Scorer
Ball Entry Cup
Player Rod Handle
Player Rod End Cap
Blue Player
16
2
2
8
8
13
A2
G01344HLA2
Rechargeable LED Soccer Ball
1
A3
A4
G01344HLA3
USB Cable
1
P21
P22
A1
G01344HLP21
G01344HLP22
G01344HLA1
Left Corner Cap
Right Corner Cap
Soccer Ball
2
2
2
C2
G01344HLC2
LED Goal Trim-A
1
C1
G01344HLC1
Junction Box
1
C6
G01344HLC6
Connecting Module
1
C3
C4
C5
G01344HLC3
G01344HLC4
G01344HLC5
LED Rail Lights-A
Scoring Sensor-A
Electronic Scorer
1
1
C7
G01344HLC7
LED Goal Trim-B
1
C8
C9
G01344HLC8
G01344HLC9
LED Rail Lights-B
Scoring Sensor-B
1
1
1
M1
G01344HLM1
Owner’s Manual
1
K1
G01344HLK1
Hardware Kit
1
