Esoteric G-25U User Manual

Troubleshooting
No power.
→Check the connection to the AC wall outlet. Make sure the outlet is not switched by a lamp switch by
plugging in another electrical device to see if the outlet is “live”.
→Press the POWER switch of the unit to turn it on.
Word sync does not work.
→Frequency of the output word clock may be invalid to the connected components. Change the frequency
setting to match that of each component. There are occasions where the word sync setting of each
component can be changed by tying other connection or setting, read well the instructions of each
component.
Cannot select suitable frequency by pressing A, B or C buttons.
→Press MASTER button to select the base frequency before selecting frequency by pressing A, B or C
buttons.
Sound is strange.
→Check the setting and suitable frequency range of connected components. If the setting is not correct,
there are occasions where the reproduced sound is strange or contains excessive noise.
EXT indicator LED blinks.
→EXT indicator blinks when the EXT mode is on and the unit cannot detect the reference signal from
external devices, or the input signal is beyond the spec this unit can input.
When the EXT indicator is blinking, confirm the setting of the connected external devices. If you do not
use EXT IN terminal, turn off the EXT mode.
Specifications
General
Power supply
Europe model . . . . . . . . . . . . . . . . . . ..AC 230 V, 50 Hz
U.S.A./Canada model. . . . . . . . . . . . . . . AC 120 V, 60 Hz
Power consumption . . . . . . . . . . . . . . . . . . . . . . . . 9W
Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7.9kg
External dimensions (W x H x D) . . . . . . . 440 x 95.5 x 342 mm
Word Synchronization output format
44.1kHz series....................................... 44.1kHz, 88.2kHz, 176.4kHz
48kHz series....................................... 48kHz, 96kHz, 192kHz.
Output...................... .........................BNC x 3 /TTL rectangular wave /75Ω
Accuracy...................... .........................±1ppm
Word synchronization input frequency range
44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz. 10MHz (±10ppm)
1.4～5Vp-p sine wave / rectangular wave
External Input jack...................... ..BNC x 1 /75Ω
Digital inputs
RCA x 2
TOS x 1
input format...................... ..S/PDIF format
Sampling frequencies (kHz)
32, 44.1, 48, 88.2, 96, 176.4, 192 (kHz)
Digital outputs
XLR x 2 (2 single or 1 AES3 DUAL)
RCA x 1
TOS x 1
Output format...................... ..S/PDIF format, AES3 DUAL format
Accessories
Power cord x 1, Felt x 3, Warranty card x 1, Owner's manual x 1
Improvements may result in specification or feature changes
without notice.

Esoteric G-25U Specifications

General Specifications

power supply (Europe model)	AC 230 V, 50 Hz
power supply (U.S.A./Canada model)	AC 120 V, 60 Hz
power consumption	9 W
weight	7.9 kg
external dimensions	440 x 95.5 x 342 mm

Word Synchronization

output format (44.1kHz series)	44.1kHz, 88.2kHz, 176.4kHz
output format (48kHz series)	48kHz, 96kHz, 192kHz
output	BNC x 3 /TTL rectangular wave /75Ω
accuracy	±1 ppm
input frequency range	44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz, 10MHz (±10ppm)
input signal level	1.4～5Vp-p sine wave / rectangular wave
external input jack	BNC x 1 /75Ω

Digital Inputs and Outputs

digital inputs (RCA)	x 2
digital inputs (TOS)	x 1
input format	S/PDIF format
sampling frequencies	32, 44.1, 48, 88.2, 96, 176.4, 192 kHz
digital outputs (XLR)	x 2 (2 single or 1 AES3 DUAL)
digital outputs (RCA)	x 1
digital outputs (TOS)	x 1
output format	S/PDIF format, AES3 DUAL format
