Folding Wheels Kit (optional accessory)
Line up the holes in the link plates and engine deck. Slide bolts M10x30 through the holes
from one side, then lock nuts M10 from the other side. Tighten down. Before compacting,
fold up the wheel kit as shown.
Paving Pad Kit (optional)
Attach the paving pad onto the base
plate as shown. Align the holes in the
base plate, paving pad and clamp
plates, and secure it with bolts and
lock washers.
M10 x 20 (3 pcs)
Engine Oil
OIL HAS BEEN DRAINED FOR SHIPPING.
Failure to fill engine sump throttle linkage with oil before starting engine will
result in permanent damage and void engine warranty.
Add oil according to engine manual. With the engine in a level position, fill to the upper
limit of the oil filler hole with the recommended oil. Check the oil level regularly.
