1 Module Overview
1 Module Overview
1.1 Features
CPU and OnChip Memory
• ESP32-S3 series of SoCs embedded, Xtensa
®
dual-core 32-bit LX7 microprocessor, up to 240
MHz
• 384 KB ROM
• 512 KB SRAM
• 16 KB SRAM in RTC
• Up to 8 MB PSRAM
WiFi
• 802.11 b/g/n
• Bit rate: 802.11n up to 150 Mbps
• A-MPDU and A-MSDU aggregation
• 0.4 µs guard interval support
• Center frequency range of operating channel:
2412 ~ 2462 MHz
Bluetooth
• Bluetooth LE: Bluetooth 5, Bluetooth mesh
• 2 Mbps PHY
• Long range mode
• Advertising extensions
• Multiple advertisement sets
• Channel selection algorithm #2
Peripherals
• GPIO, SPI, LCD interface, Camera interface,
UART, I2C, I2S, remote control, pulse counter,
LED PWM, USB 1.1 OTG, USB Serial/JTAG
controller, MCPWM, SDIO host, GDMA, TWAI
®
controller (compatible with ISO 11898-1), ADC,
touch sensor, temperature sensor, timers and
watchdogs
Integrated Components on Module
• 40 MHz crystal oscillator
• Up to 16 MB SPI flash
Antenna Options
• On-board PCB antenna (ESP32-S3-WROOM-1)
• External antenna via a connector
(ESP32-S3-WROOM-1U)
Operating Conditions
• Operating voltage/Power supply: 3.0 ~ 3.6 V
• Operating ambient temperature:
– 65 °C version: –40 ~ 65 °C
– 85 °C version: –40 ~ 85 °C
– 105 °C version: –40 ~ 105 °C
• Dimensions: See Table 1
1.2 Description
ESP32-S3-WROOM-1 and ESP32-S3-WROOM-1U are two powerful, generic Wi-Fi + Bluetooth LE MCU
modules that are built around the ESP32-S3 series of SoCs. On top of a rich set of peripherals, the acceleration
for neural network computing and signal processing workloads provided by the SoC make the modules an ideal
choice for a wide variety of application scenarios related to AI and Artificial Intelligence of Things (AIoT), such as
wake word detection, speech commands recognition, face detection and recognition, smart home, smart
appliances, smart control panel, smart speaker, etc.
ESP32-S3-WROOM-1 comes with a PCB antenna. ESP32-S3-WROOM-1U comes with an external antenna
