DESCRIPTION Page 2
DESCRIPTION
HELPY QUICK
A Built-in loudspeaker
B Connector for Esse-ti power
supply (12Vdc)
C LED indicating device operation (red)
LED indicating GSM200 signal
strength (green)
D Connector for FlashKey
E Reset pushbutton
F RJ45 connector for GSM200 module
G Jumpers for Telephone Line /
GSM200 Module selection
H Pushbutton (two contacts):
.C2: common
.NO2: normally open
.NC2: normally closed
I Built-in microphone
L Terminal blocks
