Pre-Assembly
NOTED: Hardware not shown
to actual size.
PLANNING ASSEMBLY
To prevent damage, place all parts on a soft surface during assembly.
Remove all protective caps before beginning assembly. It takes about
20 minutes for two person to complete all the assembly.
HARDWARE INCLUDED
_EE
_CC_AA
BOLTS
WASHERS
( 13mm)
(5mm)
8
8
4
Part
Description
QTY.
CC
AA
DD
( 6.35x12mm)
CAUTION: If you overload your
furniture, injuries can occur.
OBSERVE WEIGHT LIMITS
The recommended weight limits for the following products are listed below:
Table: 50 lbs
5
_BB
BOLTS
4
BB
_DD
1
PUSH PINS
Size
( 4x12mm)
(4mm)
1
EE ALLEN WRENCH
( 75mm)
FF
UMBRELLA HOLE
PROTECTOR
_FF
