8
Instructions to Convert Unit to Vertical Duct Configuration
1. Remove the 13 screws holding the Duct in place.
2. Replace the 4 screws removed from the Top Pan.
3. Turn the Duct 90 degrees counter-clockwise. Be careful not to unplug the switch from the wiring harness.
4. Align the Duct with the 3 holes at the top of the Front Panel (just below the Top Pan).
5. Insert 3 screws at the top and bottom of the duct.
6. Place the Duct Mount Strips (found in bottom of cooler) over the side Duct Flanges and insert screws 3 each side into
the holes provided (3 screws will be in installation kit).
Proceed with the installation as normal. The Side Sealer Channels will go on the same flanges as for a horizontal duct.
You may use the Side Sealers provided to close off the window above your cooler’s duct.
LIMITED WARRANTY
This warranty is extended to the original purchaser only. It does not cover damages incurred during shipping or
through accident, neglect, or abuse by the owner. Champion Cooler/Essick Air Products does not authorize any person
or representative to assume any other or different liability in connection with this cooler.
TERMS AND CONDITIONS OF WARRANTY
The BOTTOM PAN is guaranteed against leakage due to rusting out
for Eight Years. All other original parts provided
by Champion Cooler/Essick Air Products are warranted against defects in material or factory workmanship for One Year.
EXCLUSIONS FROM THE WARRANTY
Champion Cooler/Essick Air Products is not responsible for incidental or consequential damage resulting from any
malfunction.
Champion Cooler/Essick Air Products is not responsible for any damage occurring from the use of water softeners,
chemicals, descale material, or if a higher horsepower motor than what Champion Cooler/Essick Air Products
recommends is used in the unit.
Champion Cooler/Essick Air Products is not responsible for the cost of service calls to diagnose cause of trouble, or labor
charge to repair and/or replace parts.
HOW TO OBTAIN SERVICE UNDER THIS WARRANTY
Contact the Dealer where you purchased the evaporative cooler. If for any reason you are not satisfied with the response
from the Dealer, contact Customer Service Department: Essick Air Products Inc. 5800 Murray Street, Little Rock,
Arkansas 72209. 1-800-643-8341.
