CHAPTER 4
ESTEEM
APPLICATION PROGRAMS
Revised: 8 Oct 03 4-2 EST P/N AA104
TRANSPARENT AUTO-CONNECT GLOBAL
This mode is usually used for a point to multi-point applications when a customers devices include their own addressing
protocol to communicate between devices. The ESTeem packet addressing and acknowledge protocol is defeated. All ESTeems
will receive the data transmission. The 32 bit CRC error checking on received data is still enabled. This program is used in all
ESTeems, the only difference is the unit addresses.
Perform the following prior to programming the ESTeem(s) to initialize the unit to factory default settings:
1. Turn Bit 2 OFF on the RS-232C Setup Switch
2. Reset the ESTeem.
3. TYPE FA <Enter>. Please note the characters may not be echoed by the crt.
ESTeem A
----------------------------------------------------
ADD xxx (xxx = ESTeem address)
SETCON 255
TERMC ON
TERMT 10
XHF ON *
TRANS ON
SAVE
Bit 2 ON (RS-232 Switch)
Reset ESTeem
Note: Only hardware flow control can be used in this mode.
