APPENDIX B
SPECIFICATIONS
Model 192C/CHP/F/M/MHP Overall Specifications
Revised: 13 Apr 05 APX B- 3 EST P/N AA104
ESTeem Model 192F
Frequency Range 400 to 420 MHz
Frequency Selection Digitally Synthesized - Software Selectable
Frequency Stability +/- 1 ppm
Frequency Selectability 6.25KHz
RF Data Rate
19,200 bps @ 25 KHz Channel Spacing
Canada: 2163 195 214A
Emission Designator: 17K6F1D
9,600 bps @ 12.5 KHz Channel Spacing
Canada: 2163 195 214A
Emission Designator: 10K8F2D
Transmitter Modulation DC to 4800 Hz @ 19,200 bps
DC to 2400 Hz @ 9,600 bps
Transmitter Deviation 4 KHz @ 19,200 bps
3 KHz @ 9,600 bps
Transmitter RF Power Output
4 Watts
(2 Watts optional)
Transmitter Duty Cycle 100%
Transmitter Spurious & Harmonics > 55 dB down from carrier
Transmitter Rise Time 1 msec
Receiver Sensitivity: -101 dBm @ 12 dB Sinad
Receiver Spurious & Image Rejection > 50 dB
Receiver Squelch Sensitivity Software Adjustable
Receiver Adjacent Channel Rejection > 70 dB
Receiver Modulation Acceptance:
25 KHz @ 19,200 bps
12.5 KHz @ 9,600 bps
Receiver Base Bandwidth:
4.8 KHz @ 19,200 bps
2.4 KHz @9,600 bps
Transmit/Receive Switch Integral to Unit
RF Output Impedance 50 Ohms
RF Input/Output Connector TNC Female
Power Supply Voltage 10.8 to 16 VDC
Power Supply Current @ 12 VDC
400 ma Receive
1.5 A Transmit @ 2 W RF Output
2.0 A Transmit @ 4 W RF Output
Input Power Connector 2 Pin Molex (male)
Temperature Range
-30 to + 50 ° C.
Size 2.45 in. H x 9.37 in. W x 8.16 in. L.
Weight 5 lbs.
