APPENDIX D
SOFTWARE COMMANDS
Revised: 13 Sep 05 APX D- 6 EST P/N AA104
MESSform (on/off)
When enabled all of the system status and error messages will be in a formatted form.
"xx" indicates what error or message (See Error Messages and System Status Messages).
EMxx <CR> [ESTeem Error Messages]
SExx <CR> [System Error Messages]
SSxx <CR> [System Status Messages]
SSxx-xxxx <CR> [System Status Message W/Returned Value]
ON: Enabled.
OFF: Disabled.
Factory default = OFF.
MOdecontr (on/off)
ON: The mode of the ESTeem modem is controlled by pin 19 of the RS-232C connector. A low (0) directs the ESTeem into
the COMMAND mode. A high (1) directs the ESTeem into CONVERSE/TRANSPARENT mode.
OFF: The mode of the ESTeem modem is controlled by ASCII character.
Factory default = OFF
MODEL (xx)
Displays the product model of default firmware that is installed. Model should be the same as product being used. Listed below
are the model codes
19C = ESTeem Model 192C
19F = ESTeem Model 192F
19V = ESTeem Model 192V
MODCTRL
This command enables the Modicon controller protocol. For further detail Reference the EST Engineering Report on Modicon
controller interfacing.
OFF: Disabled.
Factory default = OFF.
MODUlate (on/off)
The radio modulate command. When enabled will transmit a modulated test signal when the RADIO ON command is enabled.
ON: Enabled.
OFF: Disabled.
Factory default = OFF.
MOORE (on/off)
This function enables the Moore products using Hart protocol. For further details reference the EST Engineering Report on
Moore Products interfacing.
ON: Enabled.
OFF: Disabled.
Factory default = OFF.
