7
PRO51 X PRO51 D
Engine
HONDA GXV160
4 stroke OHV
Briggs & Stratton "750 Series"
4 stroke - DOV
Piston displacement 163 cm
3
161 m
3
Stroke 45 mm 50 mm
Bore 68 mm 64 mm
Rated speed
2900 min
-1
Power at rated speed 2,9 kW 2,6 kW
Starter recoil
Decompression device mecanical
Regulator mecanical
Tank capacity 1,8 liters 1 liter
Fuel unleaded fuel
Carburetor oat type, xed main jet oat-type with ‘‘ReadyStart’’
Cooling air cooled
Air lter paper cartridge + pre-filter paper cartridge
Ignition electronic
Spark plug standard Ø 14 x 21 mm standard Ø 14 x 19 mm
Electrode gap 0,75 mm
Blade coupling device belt
Blade stop blade clutch / brake
Cutting width 51 cm
Cutting height
25, 33, 45, 60, 75, 88 mm
central height adjustment
Dimensions (Lxlxh)
Handlebar folded :
Handlebar in working position :
1210 x 555 x 600 mm
1450 x 555 x 1100 mm
Wheel diameter
front Ø 200 mm
rear Ø 215 mm
Approximate weight 59 kg 57 kg
Box capacity (option) 72 liters
Forward speed 3,2 to 4,4 kmph by variator
Sound pressure level at operating
position *
LpA = 85 dB(A)
(KpA = 2,5)
LpA = 88 dB(A)
(KpA = 2,5)
Level of vibration in handlebar **
ahw = < 4,1 m/s²
(K = 2,05)
ahw = < 3,4 m/s²
(K = 1,7)
3• TECHNICAL SPECIFICATIONS
* Reference standards for mesurements : NF EN ISO 5395-1 and -2
** Reference standards for mesurements : NF EN 1033, NF EN ISO 5395-1 and -2
