Etesia PRO51X - Technical Specifications

14
GB
3• Technical specifications
PRO51K PRO51B PRO51H PRO51X
Engine KAWASAKI FC 180 V BRIGGS & STRATTON INTEK EDGE 60 HONDA GCV 160 HONDA GXV160
4 STROKE OHV 4 STROKE OHV 4 STROKE OHC 4 STROKE OHV
Piston displacement 182 cm
3
190 cm
3
160 cm
3
163 cm
3
Stroke 50 mm 52 mm 50 mm 45 mm
Bore 68 mm 68 mm 64 mm 68 mm
Maximum power measured 6 HP / 4,4 kW at 3600 rpm 5,5 HP / 4,1 kW at 3600 rpm 4,3 HP / 3,2 kW at 3600 rpm
at the shaft output
Maximum use rate 2900 rpm 2800 rpm 2900 rpm
Starter
Recoil
Decompression device
Mecanical
Regulator
Mecanical
Tank capacity 2,5 liters 1,5 liters 1,1 liters 1,8 liters
Fuel Unleaded fuel
Carburetor
Float type, fixed main jet Float type with Primer Float type, fixed main jet Float type, fixed main jet
Cooling
Air cooled
Air Filter Paper cartridge and pre-filter Paper cartridge Paper cartridge and pre-filter
Ignition Electronic
Spark plug Standard Ø 14 x 19 mm Standard Ø 14 mm x 19 mm Standard Ø 14 mm x 19 mm Standard Ø 14 mm x 19 mm
16 mm Hexagonal
Electrode gap 0,75 mm
Blade coupling device Belt Shearing washer Belt
Blade stop
Blade clutch/brake Engine break Blade clutch/brake
Cutting width 51 cm
Cutting height 25, 33, 45, 60, 75, 88 mm
Central height adjustment
Dimensions (Lxlxh)
Handlebar folded : 1210 x 555 x 600 mm 1210 x 555 x 530 mm
Handlebar in working position : 1450 x 555 x 1100 mm 1450 x 555 x 1100 mm
Wheel diameter Front Ø 200 mm
Rear Ø 215 mm
Approximate weight 59 kg 62 kg 50 kg 59 kg
Bag capacity 72 liters
Forward speed 2,9 à 4,1 kph by variator 3,7 kph 2,9 à 4,1 kph by variator
Noise level at 81 dB(A) 81 dB(A) 82 dB (A) 85 dB (A)
control position*
Vibration levels 3 m/s
2
4 m/s
2
3,7 m/s
2
4,1 m/s
2
at the handle **
* Reference standard for mesurements = EN 836
** Reference standard for mesurements = EN 836, EN 1033, EN ISO 5349-1
