KL8800A User Manual
B5：OFF: “HEAT2” position could connect heater.
ON: “HEAT2” position could connect hot pump.
B6：OFF：Connect sub panel A.
ON：Connect sub panel B.
***Note***
1. Please turn off the system when you change any settings of the DIP jumpers, and then waiting
for 60 seconds before turn on the system again.
2. All the jumper settings have been set up ok before fab out. The user had better not change
these settings.
Ⅳ. The Operation Instruction of Output Loads
). The operation of surfing pumpⅠ
Press “ ” ” ” and “ ” key to control the surfing pump 1/2/3 to be ON/OFF. All
of surfing pumps will automatically turn off after 15 minutes.
When A5=ON, the surfing pump 1 work as a dual speed pump. The 1st time to press “ ” is
to start high speed, the 2nd time to press “ ” to turn off high speed and turn on low speed,
the 3
rd
time to press “ ” to turn off both high speed and low speed.
Ⅱ).The operation of the blower
Press “ ” key to turn on/off the blower, it will automatically turn off after 15 minutes.
Ⅲ). The operation of the light
“ ” key is used to turn on /off the LED light. The light will automatically turn off after 120
minutes.
When B2=OFF, press “ ” key once, the light will be turn on and automatically change
color at the same time; Press “ ” key again, the light will fix color; The third time to press
“ ” key, the light will turn off.
When B2=ON, the user can just turn on or turn off the light.
