EN 17
Control panel
The control panel is located on the door of the freezer section of the SBS refrigerator. When the
appliance is switched on for the first time, the backlight for the pictograms lights up. If no keys
are operated and the doors remain closed, the light will turn off after 60 seconds.
6
4
5
3
1
2
1. Intensive freezing pictogram
2. Temperature display (freezer compartment)
3. Temperature adjustment key (freezer compartment) and intensive freezing function
4. Intensive cooling pictogram
5. Temperature display (refrigerator compartment)
6. Temperature adjustment key (refrigerator compartment) and intensive cooling function
The recommended temperature is 4 °C for the refrigerator compartment and -18 °C for
the freezer compartment.
Disconnect from the power mains; the appliance is off.
DESCRIPTION OF THE APPLIANCE
