ETNA T110VRVSA - Operation

EN 3
OPERATION
Description
Read the separate safety instructions before
using the device!
Igniting and setting
1. 0 setting
2. zone indication
3. Low setting
4. High setting
Each burner can be adjusted continuously between high and low heat.
Burners with electric ignition:
• Press the control knob and turn it anticlockwise. The burner ignites.
• Keep the control knob fully pressed for at least 3 seconds between
high and low settings. The thermocouple safeguard is activated.
Burners without electric ignition:
• Press the control knob and turn it anticlockwise. Light the burner
with a match.
• Keep the control knob fully pressed for at least 3 seconds between
high and low settings. The thermocouple safeguard is activated.
1
4
3
2
1. standard burner
2. rapid burner or wok burner (depending on model)
3. simmer burner
4. pan support
5. drip tray
6. control knob
32
6
5
4
1 1
