VGA
1
USB 3.0 USB 3.0
A B
C
×
VGA
1
USB 3.0 USB 3.0
HOST1
HOST 2
HOST 2
HDMI 1
HDMI 2
HDMI 3
VGA
C
B
D
E
Windows
Mac OS
A
For Windows host:
Windows Support Quad Display on 4 external monitors. HOST1
expand to HDMI1 monitor. HOST2 can expand to HDMI2 + HDMI3
+ VGA, and support Triple display. Note: For HOST2, when three
external monitors output video simultaneously, the Windows
laptop will be blank screen.
Note:
For macOS, these three monitors(HDMI2 + HDMI3 + VGA)
connected to HOST2 only have the same display.
HDMI 2 HDMI 3 VGA
DC 12V3A
DC 12V3A
. 07 .
