VGA
1
USB 3.0 USB 3.0
DC 12V3A
DC 12V3A
VGAHDMI 3
HOST2
HDMI 2
For Windows host with 1 type c port, connect up to 3 monitors:
HDMI2 + HDMI3 + VGA and support Triple display, when
connecting your laptop to the HOST 2 port. Note: When three
external monitors output video simultaneously, the Windows
laptop will be blank screen.
Windows
A
B C
2. When you have two Thunderbolt 3 host（Support
Quad Display）
For macOS host:
HOST1 expand to HDMI1 monitor, HOST2 can expand to HDMI2 +
HDMI3 + VGA, but these three monitors connected to HOST2 only
have the same display.
VGA
1
USB 3.0 USB 3.0
HOST1
HOST 2
HDMI 1
HDMI 2
HDMI 3
VGA
D
B
D
D
Mac OS
A
C
. 06 .
