7. Mount the device onto the mounting bracket, and then secure it with a screw on each side.
8. Turn on the circuit breaker of your home.
5. To avoid difficulty when mounting the device onto the mounting bracket:
• Make sure the wires are not too thick.
• Try to bend the wires at a 90° angle.
6. Loosen the wire screws, insert the neutral, ground, and live wires into the connectors, and
then tighten the wire screws to thoroughly secure the wires.
North America Europe
Ground Green / Yellow Green / Yellow
Neutral White Blue
Live Black Brown
The wire colors vary depending
on region.
