03 04
microSD memory card can only be used for firmware
upgrade, it cannot be used to store video recordings.
Camera Features:
1
Standard camera lens
4
Speaker
2
Microphone
5
Micro USB port
3
Power LED Status indicator
6
Pairing button
Setting Up the Camera and Monitor
Monitor Installation
Fully charge the monitor before use. To charge:
Connect the baby monitor to the monitor adapter with the Micro
USB cable, and then connect the adapter to a power outlet.
Connect the other end of the baby monitor’s Micro USB power
cable to the Micro USB port in the monitor to charge it. Press and
hold the power button for 2 seconds to turn the baby monitor on.
Camera Installation
Connect the baby camera’s Micro USB power cable to the camera
adapter (5V 2A), and then connect the adapter to a power outlet.
Finally, connect the other end of the baby camera’s micro USB
power cable to the micro USB port in the camera.
