Detach the Existing Doorbell Button
If you already have existing doorbell wiring:
1. Remove the existing doorbell button with a Phillips-head
screwdriver (not provided).
2. Pull the two wires out carefully when removing the
existing doorbell. Straighten the wire ends if necessary.
Choose a Location
1. Take the video doorbell to your front door and check the
live view in the app. Choose a location where you can see
the desired field of view. Consider the following factors:
• Check if you can reuse the existing holes and anchors in
the wall or door frame.
• If you want to place the doorbell near a side wall, make
sure the wall isn't in the field of view. Otherwise, the IR
light will be reflected and the night vision will be blurred.
• If you are drilling the mounting holes for the first time, the
recommended height is 48" (1.2m) above the ground.
• To adjust the angle, use the 15º mounting wedge as a
supplementary mounting bracket.
1.76m(5’9”)
1.2m (48")
0.3m
(12")
1m
(40")
