EUFY S1 - Page 5

Bottom
❸
❷
❷
❶
❹
❹
❺❻❼
❶
Rolling Mop
❷
Wheels (×2)
❸
Brush Guard
❹
Side Brushes (×2)
❺
Rolling Brush
❻
Swivel Wheel
❼
Carpet Detection Sensor
Dirty Water Reservoir
❷
❸
❺
❶
❹
❶
Robot Water Sink Filter
❷
Robot Water Sink
❸
Dirty Water Reservoir Release
Buttons
❹
Dirty Water Reservoir Filters (×3)
❺
Dirty Water Reservoir
Dust Bin
❶
❸
❷
❹
❺
❶
Dust Bin Handle
❷
Release Latch of Back Cover
• Open to clean the interior of dust bin
❸
Pre-Filter
❹
High-performance Filter
❺
Release Latch of Top Cover
• Open to take out the
High-performance Filter
❶
❶
Anti-Drop Sensors (×6)
