29
5.4.4 FREEZING THE TIMES
Press buttons (12) and (13) togheter. Once released the adjustment of the
dose delivery time is locked. In addition buttons (12) and (13 ) are darkened
on the display. Press both buttons (12) and (13) again to unlock the
functions.
5.4.5 DOSE COUNTS
Press the central button (11) for 5 seconds and then select one of the counts:
• Dose 1 button (15) : access to the count of dose 1s dispensed;
• Dose 2 button (16) : access to the count of dose 2s dispensed;
• Dose 1 button (15) and dose 2 button (16) : access to the dose count for
continuous doses dispensed expressed in seconds;
Only the selected keys remain lit on the display or the numbers of the doses are shown
two by two in succession. For example, if the total number of doses is 142536, the
display shows 14, 25 and 36 for two seconds each.
After the last pair of digits, there is a pause for a few seconds and then the sequence
starts again.
To exit the count, press the central button (11) .
5.4.6 DISPLAY BRIGHTNESS ADJUSTMENT
Press the central button for 5 seconds (11) and then select buttons (12) or
(13) respectively to decrease or increase brightness. On the screen display (10)
the levels of brightness will appear from 1 to 7.
To exit the count, press the central button (11) .
5.4.7 STANDBY
After 1 minute of inactivity the display will go into standby mode with only the central
button staying active (11) . To exit the standby mode press the central button (11)
. On the display the main screen will be activated.
