Fork arm
Attaching head
Needle
Needle
screw & clamp
Needle bar
Fork arm
* The walking foot accessory is optional. It is not included with this
machine.
It is easier to guide the fabric and you have a better view of the
seam when using the standard, regular foot on your machine. Your
EURO-PRO sewing machine offers excellent stitch quality on a wide
range of fabrics from delicate chiffons to multiple layers of denim.
The "Walking foot" accessory equalizes the feeding of the upper and
lower layers of fabric and improves the matching of plaids, stripes
and patterns. This foot helps to prevent uneven feeding of very
difficult fabrics.
Always try to sew first without the walking foot accessory
which should be used only when necessary.
1. Lift the presser foot bar.
2. Remove the "foot holder" by opening counter clockwise the
presser bar attaching screw. (3)
3. Attach the "walking foot" to the machine in the following way.
i) The fork arm should fit into the needle screw and clamp. (2)
ii) Slide the plastic "attaching head" from your left to right so that
it is fitted into the "presser foot bar".
iii) Lower the "presser foot bar".
iv) Replace and tighten clockwise the "presser bar attaching
screw".
4. Make sure both the "needle screw" and the "presser bar attaching
screw" are tightly secured.
5. Draw the bobbin thread up and place both the bobbin thread and
the needle thread behind the walking foot attachment.
12
3
46
The walking foot accessory
Presser bar attaching screw
Presser foot bar
