Kit Contents
Hub Motor laced to Wheel Controller
Throttle Cruise Control with Brake Inhibits
(Standard with Phoenix, optional on
RoadRunner and Sparrow)
Wire Set with Charger Port and Key
Switch
Jumper wires
Fuse Holder with Fuse Batteries
Battery Charger Rack or Basket
Bag Zip Ties
Install the Tire
1. Remove the original front
wheel from your bike.
2. From this wheel remove the
tire and tube for use on your
new Electric Wheel.
3. Push the tire and tube,
starting with the valve, onto
the rim, one side at a time,
being careful not to pinch
the tube.
4. Inflate to about 5 lbs
pressure and check to see
that the tire is evenly seated
all the way around the rim
on both sides. Inflate to 20
lbs pressure and repeat.
5. Inflate to the full pressure specified on the sidewall of your tire.
About tires
The higher the pressure, the less rolling resistance. Tires capable of higher pressure will
give you better range and speed. The smoother the tire, the less rolling resistance. Slicks
give you better range and speed than knobbies.
Install the Wheel
6. If you don’t have a bike stand, turn the bike upside down and rest it on the seat
and handlebars. Use wood blocks or other material to protect the seat and any
accessories on the handlebars.
7. Make sure the front brake arms are out of the way so the tire on your new wheel
will mount bypass them easily. Some brakes require that you loosen the cable.
Others have a quick-release for the cable.
Crystalyte Hub Motor Kit Home Assembly Guide
2006 EV Depot, a Priority Fulfillment and Distribution, LLC Company 3 of 20
