48 volt wiring
36 volt wiring
Wired battery packs. This is what we’ll end up with at the end of this procedure. We spend
a lot of time describing battery wiring because mistakes can cause component failure.
Particularly susceptible to failure is the charger. If you have your pack wired incorrectly,
your charger is likely to blow. If you have a Soneil charger, the fuse will blow, but the
charger will survive.
1
Set your batteries on a non-metallic workbench as shown.
