Cancel Button – This Silences the
system when in alarm state
Manual Call Point – Fully activates
the system
A Button – Used to access the user
menu
B Button – Runs a silent test, any
units connect illuminate their LED’s
System Status LED’s
Touchscreen – Most operations are
controlled via the Touchscreen
