EVCHARGERS EVSE - Status Description


PLUGINATEVCHARGERS1800‐PLUGINevchargers.com.au
Normal Working Status Chart
"Status" Area Status Description
"Scheduled Time"
Area
Left button for
"Time"
Right Button for
"Amps"
LED Light Circle
Ready Ready and not connect to EV yet 0-6 Available Available Blue light static
Connected
Connected with EV and not
start charging
0 Not available Not available Blue light slowly flashing
Waiting
Connected with EV and waiting
for the scheduled time
1-6 Not available Not available Blue light slowly flashing
Charging Connected with EV and charging 0 Not available Not available Blue light running
