23
• Voltage: 230 V~ 50 / 60 Hz
• max. connected load: 750 VA
• max. load current: 6 A (max. 5 A per channel)
• Connection terminals: 1.5 mm² rigid wire
• Flush-mounted socket dimension: ø 60 mm, min. 35 mm depth
• Ambient temperature: -10 °C to 50 °C
• Operating humidity: max. 85%, non-condensed
• Protection rating: IP20
• Frequency range: 2402 - 2480 MHz (BLE) / 2405 – 2480 MHz (Thread)
• RF Power: max. 12 dBm (EIRP)
Shutter up NeutralOuter conductor /
Phase
Shutter down
