Connect Eve Shutter Switch
2
• : Shutter up
•
: Shutter down
• L: Outer conductor / phase
(current-carrying line)
• N: Neutral line
Eve Shutter Switch requires that
a neutral line is connected. If
the outlet is not equipped with a
neutral line, Eve Shutter Switch is
incompatible with this outlet.
Eve Shutter Switch does not
require a connection to a
protective conductor / ground
wire (PE, usually green/yellow).
