4 5
UNFOLDING THE STROLLER
To protect flooring, place a protective covering (cardboard, towel,
small rug or blanket) beneath the stroller during assembly.
To unfold stroller, push safety button and squeeze fold release.
Lift up on Parent’s Handle to open position.
To lock the stroller in the open position, pull upward until the
stroller opens fully with an audible click.
Make sure the stroller locks in the open position by pushing
down on the parent’s handle and checking the lock indicator.
Frame
CLICK!
IDENTIFICATION OF PARTS
Cupholder
Front Wheel Assembly (2)
Parent’s Handle
Lock Indicator
Green = Locked
Red = Not Locked
Bumper Bar
To avoid injury to fingers or hands, care must be taken
when folding or unfolding stroller to prevent finger injury
in hinge areas.
WARNING
DEATH or SERIOUS
INJURY can occur.
Helpful Hint: When unfolding with two hands, place hands on each side of handle
with palms facing up. Lift up until stroller opens fully with an audible click.
Turn stroller so front of stroller is facing upwards, as shown.
To attach front wheels, line up metal pin with hole in front wheel
mount and push on to frame as shown until it clicks into place.
PULL ON wheels to make sure both of them are securely
attached.
To remove, insert at tool into slot
and pull wheel off stroller.
CLICK!
INSTALLING THE WHEELS
INSTALLING THE BUMPER BAR
To attach bumper bar, line up bumper bar, ensuring logo is
upright, and push tabs into openings on stroller. Make sure
bumper bar locks into position with audible clicks.
PULL on the bumper bar to make sure it is locked into
place.
To remove the bumper bar, push both tabs
and remove the bar from the stroller.
CLICK!
CLICK!
