11
Child Requirements
Rear-Facing Mode
OPTIONAL: To ensure a better t for
smaller infants, the Body Pillow (pg. 43)
and/or Head Pillow (pg. 46) may be used
in REAR-FACING mode ONLY.
For REAR-FACING installation, Recline
Ball should be in correct zone for child
size:
• White Zone: 1.8 - 9 kg (4 - 20 lbs)
• Black Zone: 9 - 22.6 kg (20 - 50 lbs)
Chest Clip at armpit level
Shoulder straps
must be at or
just below
child’s
shoulders.
Top of head
MUST be 2.5
cm (1 in) or
more below top
of headrest or
shell.
Always use tether strap in rear facing
harness installation.
Ball must be completely in proper zone for child size.
Vehicle MUST be on level ground.
Rear Facing
1.8 - 9 kg (4 - 20 lbs)
Rear Facing
9 - 22.6 kg (20 - 50 lbs)
25809693 8/22
