54
Removing and Installing the Seat Shell from the Base
Installing the Seat Shell to the Base
To install the Seat Shell to the Base:
1. Locate the white arrow on the front of the Seat Shell (see pg. 53).
2. Align the arrow on the Seat Shell with one of the two white arrows on the
Base.
3. Place the Seat Shell on the Base.
NOTE: The Harness Adjustment Strap
can interfere with the seat lock. DO
NOT allow the strap to get caught
between the Seat Shell and Base
during installation.
4. Rotate the seat in either direction to
ensure it is properly installed.
NOTE: The seat will not rotate in the forward-facing direction unless it is fully
reclined.
or
