Three pin female
Wiring sequence Standard color Function
4.3V
GND
HC White
Black
Red Throttle positive
Throttle negative
Throttle signal
Turn the plug:
Five pin male
Wiring sequence Standard color Function
LIGHT
LL
RL Green
Black
Red Headlight positive
Positive electrode of left turn
signal lamp
Positive pole of right turn signal lamp
HORN Blue Speaker positive
NC Yellow -
Headlight plug：
