Chapter3DescriptionofInstrumentpanel
3.1FrontPanel
ThefrontpanelofPF9804isshowninFigure3.1.
Figure3.1 TheFrontPanelofPF9804
ThefrontpanelofPF9810/PF9811isshowninFigure3.2
.
Figure3.2 TheFrontPanelofPF9810/PF9811
3.1.1IndicativeFunctionandOperationKeysonthepanel
Table3.1 IndicativefunctionandOperationKeysonthepanelofPF9804
Functional
classification
OperationKeys FunctionDescription
Displayswitching
FUNCTION(therightofD
displaywindow
Windowdisplayswitchbutton
Whenintheupperandlowerlimitstateof
activepower,thekeybeusedtoswitchthe
