EverFocus EPN3600 - EverFocus EAN800 A Camera; EAN800 A Specifications

www.everfocus.com
Ordering Info
Dimensions: mm/in
2012 EverFocus Product Catalog Vs 1.1 - Models vary in different countries. Visit www.everfocus.com and select your country for additional ordering and specication information.
EverFocus is not responsible for typographical errors. Product specications are subject to change without notice.
IP Solutions
Day/Night IP Box Camera with WiFi Option
EAN800A
EAN800A: IP Box, 520 TVL
Features
• H.264/PJEG-4/MJPEG digital signal output with up
30 FPS at full D1
• H.264/MPEG4/MJPEG output for simultaneous live
monitoring and high resolution recording
• Supports 4 independent video streams that
can provide different compression formats and
resolutions
• 12VDC and Power Over Ethernet (PoE) IEEE
802.3af
• BNC test monitor output for the convenience of
quick focus and diagnostics right at the camera site
• Built-in SD memory card slot for local storage
(supports SDHC)
• Smart Event Wizard for motion detection, schedule
and alarm recording to PC or SD card
10mm/0.39”
136 mm/5.35”
48.5 mm/1.91”
13 mm/0.51”
Back View
56.5 mm/2.22”
7 mm/0.28”
68.5 mm/2.72”
Front View
Bottom View
Side View
H.264/
MPEG4/
MJPEG
Smart Event
Wizard
Day Night
Web Viewer
Two-Way
Audio
Motion
Detection
Specications
Part Number EAN800A
Pickup Device 1/4” Sony Ex-View HAD CCD
Effective Pixels NTSC: 768 (H) x 494 (V)/ PAL: 752 (H) x 582 (V)
Sensitivity 0.4 Lux/F=1.2
Day/Night Yes
Lens Optional C/CS mount, manual/DD control supported
Video Output BNC socket, composite 1.0Vp-p/75 ohm
Video Resolution
NTSC: 4CIF (720X480), VGA (640X480), CIF (352X240),
QVGA( 320X240), QCIF(176X144)
Video Compression H.264/MPEG4/MJPEG
Video Quality 8 levels adjustable
Frame Rate up to 30 FPS at full D1
Interface
10Base-T/100Base-TX auto-negotiation, FJ-45 socket.
Supports MDI/MDI-X auto cross function
Supported Protocols
Built-in IEEE 802.11b/g WLAN (EAN800AW) HTTP, TCP/
IP, UDP, RTP, RTSP, FTP, SMTP, DHCP, DNS, DDNS,
NTP
Bandwidth Control Min. 64 k bit per sec. adjustable
Max Client Limit 32 clients simultaneously
Power Over Ethernet Yes (PoE 802.3af)
Alarm Input 1
Alarm Output 1
Audio In/Out Built-in mic, and option 3.5mm stereo line input/ line out
Operation Mode Two-way audio
Event Trigger
Alarm Input, Manual Trigger, Motion Detection and
Schedule Recording
Notication
Trigger alarm output, email notication, upload video to
FTP, record video to SD card, record video to PC and
network alarm
Pre/Post Alarm Buffer 48MB RAM reserved for pre-alarm (record up to 120 sec.)
SD Card Supports SD and SDHC for local storage
Power Supply 12VDC & PoE
Power Consumption
5W max (12VDC for EAN800A) 6.5W max (12VDC for
EAN800AW)
Weight 1.102 lbs
Dimension 5.35” x 2.72” x 2.22”
Operating Temp 0°C- 40°C/ 32°F - 104°F
Humidity <90% not condensing
Certications CE, FCC, RoHS
Note: Lens Sold Separately
