EverFocus EZ930F - 2. Cable Description

EZ930F/9 5 0 F eZ.HD Outdoor IR Bullet Camera
7
2. Cable Description
No. Name Descriptions
1 Power Cable Connect to a 12VDC or 24VAC power source.
2 Video Output
1080p, 720p and 960H output, using a 75 Ohm BNC-type coaxial
cable.
3 Test Lead Connect to a monitor for setting image aim and focus.
4
DC Power Pigtail
Cable
Optional power pigtail cable. The red wire is positive (+); while the
black wire is negative (-).
