8
1.3 Specifications
Pickup Device 1/3” Sony Megapixel Color Progressive CMOS Sensor
Sensitivity 1lux/F=1.4; 0lux(IR LED ON)
S/N Ratio Max. 50dB
Video Format Main Output HDcctv 1.5Gb/s digital system
Resolution Main Output 1280x720
Video Mode Main Output Field select 720p25, 720p30, 720p50, 720p60
Main Output Connector BNC
Video Format Test Output NTSC/PAL selectable
Test Output Connector Pin header; adapter cable to BNC supplied
Exposure Control via lens DC iris
Lens Type Vari-focal lens, Auto Iris, f=3~9mm
True Day/Night Control Yes (Auto IR cut filter removal)
Back Light Compensation On/Off selectable
Auto Gain Control Yes (level 0~150)
Auto White Balance ATW/Push/Manual
DNR Off/Low/Mid/High selectable
OSD Menu Yes (controlled from 5-Axis joystick control)
Image Flip Off/H Flip/V Flip/HV Flip
IR Wavelength 850nm
IR Range Up to 45m (~150 ft.)
Power Source & Consumption 24VAC: 12W max. (~500mA)
12VDC: 1.1A max.
Dimensions
196mm(L) x 83mm(H) x 110mm Diameter(W)
12.9in.(L) x 3.26in.(H) x 4.33in. Diameter(W)
Weight 2kg /4.4 lbs
Operating Temperature -10°C~50°C ; 14°F~122°F
Weather Proof IP67 rated
Vandal Resistant Yes
Certifications FCC/CE; HDcctv Alliance Base Line Compliance
