Everlasting BASIC TRAY - Page 3

2
ENGLISH
ATTENTION: any request for intervention, technical support and spare part must refer to the SERIAL
NUMBER on the CE label, on the manual cover or on the compressor motor. The producer declines any
responsibility for any improper or not reasonably foreseen usage of the blast chiller and for any operation
carried out by neglecting the indications listed on the manual.
The main general safety standards are listed below:
- Do not use or place electrical devices inside the refrigerated compartments if they are not of the
type recommended by the manufacturer
- Do not touch the blast chiller with damp or wet hands or feet
- Do not use the blast chiller barefoot
- Do not insert screwdrivers or other objects between the guards or moving parts
- Do not pull the power cord to unplug the blast chiller from the electricity network
- The blast chiller is not intended to be used by persons (including children) with physical or mental
problems, or lack of experience and knowledge, unless they are controlled or instructed in using the
unit by a person responsible for their safety. Children must be supervised to ensure that they do not
play with the appliance.
- Before carrying out any cleaning or maintenance, disconnect the blast chiller from the mains power
supply by turning off the main switch and pulling the plug
- In the event of failure and/or malfunction of the blast chiller, turn it off and to refrain from any attempt
to repair or intervene directly. It is necessary to exclusively contact a qualified technician.
The blast chiller is composed of a modular single body insulated with expanded polyurethane with
42 kg/m3 density, internally covered in Stainless Steel AISI 304 and externally by different materials.
In the design and construction, all measures have been adopted to ensure a blast chiller that complies
with safety and hygiene requirements, such as: rounded interior corners, deep drawing with drain on
the outside for the condensate liquids, no rough surfaces, fixed guards on moving or dangerous parts.
The products must be stored in observance of the load limits given in the table, in order to ensure
an efficient circulation of air inside the blast chiller.
Load capacity
Tipo/Type
BASIC
TRAY
MINI
BASIC
TRAY
04
BASIC
TRAY
05
BASIC
TRAY
07
BASIC
TRAY
10
BASIC
TRAY
15
GN 2/3
Nr° 3 Pitch 53 mm.
GN 1/1
Nr° 4 Pitch 70 mm.
Nr° 5 Pitch 52,5 mm.
Nr° 7 Pitch 35 mm.
GN 1/1
Nr° 5 Pitch 70 mm.
Nr° 6 Pitch 52,5 mm.
Nr° 9 Pitch 35 mm.
GN 1/1
Nr° 7 Pitch 70 mm.
Nr° 9 Pitch 52,5 mm.
Nr° 13 Pitch 35 mm.
GN 1/1
Nr° 10 Pitch 70 mm.
Nr° 12 Pitch 52,5 mm.
Nr° 19 Pitch 35 mm.
GN 1/1
Nr° 15 Pitch 70 mm.
Nr° 20 Pitch 52,5 mm.
Nr° 30 Pitch 35 mm.
Nr° 2 Nr° 4 Nr° 6 Nr° 9 Nr° 12 Nr° 18
-
Nr° 1 Nr° 2 Nr° 3 Nr° 4 Nr° 6
The installation must be performed exclusively by a qualified technician
