Everlasting BASIC TRAY - Page 30

29
ENGLISH
Display and modify parameters
BUTTONS DISPLAY
Press the UP and DOWN buttons at the same time for 4 seconds PA
Press CHILLING 0
Press the DOWN button and set the Password -19
Press CHILLING PA
Press again the UP and DOWN buttons at the same time for 4
seconds
SP (rst parameter)
Scroll the parameters with the UP button Parameter required
Press CHILLING to display the value
Edit the parameter using the UP and DOWN buttons Modied value
Press CHILLING to conrm the new value
Exit from the program setting pressign both the UP and DOWN buttons or do not operate for 60
seconds
CONFIGURATION PARAMETERS ABF MINI /03/05 E-C
NB only the highlighted parameters can be modied by maintenance service. The other parameters can be modied only after
reference/authorization by our technical department.
Par. Min. Max. Unit Default Analogue inputs
CA1 -25.0 25.0 °C °F (1) 0.0 cabinet probe offset
CA2 -25.0 25.0 °C °F (1) 0.0 needle probe offset
CA3 -25.0 25.0 °C °F (1) 0.0 evaporator probe offset
CA4 -25.0 25.0 °C °F (1) 0.0 condenser probe offset
PO 0 1 - - - - 1 probe type 0 = PTC 1 = NTC
P1 0 1 - - - - 1 °C decimal point °C 1 = si
P2 0 1 - - - - 0 temperature unit of measurement (2) 0 °C 1 °F
P3 0 1 - - - - 1 enabling the needle probe 1 = si
P4 0 1 - - - - 1 enabling the evaporator probe 1 = si
P5 0 1 - - - - 0
fourth input function
0 = high pressure input (digital input)
1 = condenser probe (analogue input)
P8 0 250 ds 5 delay displaying temperature variation detected by the probes
Par. Min. Max. Unit Default Main regulator
rO 0.1 15.0 °C/°F(1) 2.0 parameters differential r7, r8, r9, r10, r11 e r12
rl 1 500 min 90 duration of time-controlled blast chilling
r2 1 500 min 240 duration of time-controlled deep freezing
r3 -99.0 99.0
°C / °F
(1)
3.0
temperature-controlled blast chilling end time temperature; also end tem-
perature of the temperature-controlled soft deep freezing phase (tempe-
rature detected by the needle probe); also see parameter r5
r4 -99.0 99.0
°C / °F
(1)
-18.0
temperature-controlled deep freezing end temperature (temperature de-
tected by the needle probe); also see parameter r6
r5 1 500 min 90
maximum duration of temperature-controlled blast chilling; also see pa-
rameter r3
r6 1 500 min 240
maximum duration of temperature-controlled deep freezing; see parame-
ter r4 also
r7 -99.0 99.0
°C °F
(1)
0.0
work set-point during blast chilling; also work set-point during the soft
deep freezing phase (cabinet temperature); also see parameter r0
r8 -99.0 99.0
°C °F
(1)
-40.0
work set-point during deep freezing (cabinet temperature); also see pa-
rameter r0
