31
ENGLISH
d1 0 3 - - - - 2
type of defrosting 0 = electrical (the compressor will be switched off du-
ring defrosting, the defrosting output will be activated and the evaporator
fan will be switched off) 1 = hot gas (the compressor will be switched on
during defrosting, the defrosting output will be activated and the evapora-
tor fan will be switched off) 2 = air (the compressor will be switched off du-
ring defrosting and the defrosting output will be activated; the evaporator
fan will be switched on, independently from the conditions of the door, i.e.
independently from the door micro switch input status) 3 = air with door
open (the compressor will be switched off during defrosting and the defro-
sting output will be activated; the evaporator fan will be switched on, on
condition that the door is open, i.e. that is on condition that the door micro
switch is active and that the parameter i0 is set at values different to 0)
d2 -99.0 99.0 -C °F (1) 8.0
defrosting end temperature (evaporator temperature); also see parameter d3
d3 0 99 min 30
if parameter P4 is set at 0, duration of defrosting if parameter P4 is set at
1, maximum duration of defrosting; see also parameter d2 0 = defrosting
will never be activated
d4 0 1 - - - - 0 defrosting on start-up of blast chilling and deep freezing1 = yes
d5 0 99 min 0
defrosting delay on start-up of storing 0 = defrosting will be started on
expiry of the time established with parameter d0
d7 0 15 min 2
dripping duration (the compressor and the evaporator fan remain off du-
ring dripping and the defrosting output will be deactivated)
d15 0 99 min 0
minimum duration of compressor switch-on on activation of defrosting so
these can be activated (only if parameter d1 is set at 1) (8)
d16 0 99 min 0
duration of pre-dripping (only if parameter d1 is set at 1; the compressor
and evaporator fan will be off during pre-dripping and the defrosting ou-
tput will remain activated)
Par. Min. Max. Unit Default Temperature alarms (9) (10)
A1 0.0 99.0
°C / °F
(1)
10.0
cabinet temperature below which the minimum temperature alarm is acti-
vated (relative to the work set-point, i.e. “r10 - A1” during post blast chil-
ling storage and “r11 - A1” during post deep freezing storage; (“AL” code);
also see parameter A11 (4)
A2 0 1 - - - - 0 enabling of minimum temperature alarm (“AL” code) 1 = yes
A4 0.0 99.0
-C / °F
(1)
10.0
cabinet temperature above which the maximum temperature alarm is ac-
tivated (relative to the work set-point, i.e. “r10 +A4” during post blast
chilling storage and “r11 +A4” during post deep freezing storage; (“AH”
code); also see parameter A11 (4)
A5 0 1 - - - - 1 enabling of maximum temperature alarm (“AH” code) 1 = yes
A7 0 240 min 15 temperature alarm delay (“AL” code and “AH” code)
A8 0 240 min 15
maximum temperature alarm delay (“AH” code) from the conclusion of
evaporator fan stop and storage start-up
AA 0 240 s 5
duration of buzzer activation on conclusion of blast chilling and deep freezing
All 0,1 15,0 -C °F (1) 2,0 parameters A1 and A4 differential
Par. Min. Max. Unit Default Evaporator and condenser fan
FO 0 2 - - - - 1
evaporator fan activity during pre-cooling, blast chilling and deep freezing
0 = off 1 = on; see also parameters F16 and F17 2 = parallel to the com-
pressor; also see parameters F9 and F17
F1 -99.0 99.0
°C °F
(1)
10
evaporator temperature above which the evaporator fan is off during sto-
rage (only if parameter F2 is set at 3); also see parameter F8 (11)
F2 0 3 - - - - 2
evaporator fan activity during storage 0 = off 1 = on 2 = parallel to the
compressor; also see parameter F9 3 = on; also see parameter F1
F3 0 15 min 2
duration of evaporator fan standstill (the compressor can be on during
evaporator fan standstill, the defrosting output will remain deactivated
and the evaporator fan will remain off)
F8 0.1 15.0
°C / °F
(1)
2.0 F1, F16 and F17 parameters differential
F9 0 240 s 30
evaporator fan switch-off delay from compressor switch off (only if para-
meter F0 and/or parameter F2 are set at 2)
F15 0 240 s 15
evaporator fan delay from door closure, i.e. from the deactivation of the
door micro switch input
F16 -99.0 99.0 -C °F (1) 70.0
evaporator temperature above which the evaporator fan is off during pre-
cooling, blast chilling and deep freezing (only if parameter F0 is set at 1);
also see parameter F8 (11)
F17 -99.0 99.0 -C °F (1) 90.0
cabinet temperature above which the evaporator fan is off during pre-
cooling, blast chilling and deep freezing (only if parameter F0 is set at 1 or
2); also see parameter F8
Par. Min. Max. Unit Default Digital imput
