FEATURES
1
2
3
4
5
13
6
7
8 9 10 11
12
15
14
1. Negative (–) Black Clamp
2. Backlit LCD Screen
3. Built-in 120 Volt AC Charger (under protective cover)
4. 2-LED White Area Light
5. Positive (+) Red Clamp
6. USB Charging Ports
7. Compressor Power Button
8. Decrease Compressor Pressure Control Button (–)
9. USB Power Button
10. Area Light Power Button
11. Increase Compressor Pressure Control Button (+)
12. Jump Starter Power Switch
13. Nozzle Adapter
14. Air Hose Storage
15. Air Hose and Sure Fit
®
Nozzle
DIGITAL LCD SCREEN
BATTERY STATUS ICON
DIGITAL DISPLAY (VARIES BY
FUNCTION)
ALARM ICON
ARROW ICONS
CLAMP ICONS
BATTERY VOLTAGE
INDICATOR
COMPRESSOR ICON
JUMP STARTER ICON
FAULT ICON
COMPRESSOR
PRESSURE INDICATOR
USB ICON
